Audio:
Not Equipped, Accessory Options Available
Type de siège:
Color-Matched, Front Bolstered Bucket Seats with 4-Way Adjustability (Including 6 in front to Back Toolless Seat Sliders with Tilt Adjustability) and Retractable Click-6 Harnesses, Rear Stadium Style Seating with Non-Retractable 6-Point Har
Charging system:
High Output 1700w charging system @ 3,000 RPM
Instrumentation:
Dual-sweep Analog Dials w/ 4'' LCD Rider Information Center: User Selectable Blue/Red Backlighting & Brightness, Programmable Service Intervals, Speedometer, Tachometer, Odometer, Tripmeter, Clock, Hour Meter, Gear Indicator, Fuel Gauge, Co
Lighting:
Signature White LED, Low/High & Red LED Tail/Brake Lights
Type d’attelage:
Non équipé
Système de chargement:
Lock & Ride® Convertible Fold Flat Rear Seat Storage with Integrated Tie Down Points, 27.7 x 52.8 x 19.5 in (70.4 x 134.1 x 49.53 cm) Factory Equipped Cargo Liner
Direction assistée électronique:
Rack Mounted High Assist Electronic Power Steering with Quick Turn Rack
Portières:
Portières pleines avant et arrière
Dimensions de la caisse (l x l x h):
29.5 x 23.8 x 8.1 in (75 x 60.5 x 20.6 cm)
Capacité de la caisse:
136,1 kg (300 lb)
Garde au sol:
40,6 cm (16 po)
Taille totale du véhicule (l x l x h):
165.5 x 74 x 76.5'' (420 x 188 x 194 cm)
Capacité de charge utile:
408 kg (900 lb)
Empattement:
339,1 cm (133,5 po)
Freins avant et arrière:
Disque hydraulique à quatre roues doté d’étriers avant à alésage triple et arrière à alésage double, rotor Top Hat en aluminium
Frein de stationnement:
Transmission de stationnement
Système de frein moteur (ebs):
Non équipé
Système de carburant/batterie:
Injection électronique de carburant
Type de système de transmission:
Pro Performance True 2WD/4WD/4WD Lock
Roues:
5-Lug, 15'' Cast Aluminum Rim
Pneus avant:
32 x 10-15 Maxxis Rampage Fury 8-Ply Rated Wheel Size 15x7
Pneus arrière:
32 x 10-15 Maxxis Rampage Fury 8-Ply Rated Wheel Size 15x7
Entrainement:
PVT automatique P/R/N/L/H
Type de moteur:
Quatre cylindres en ligne DACT à 4 temps
Capacité du réservoir:
46,56 l (12,30 gal)
Système de refroidissement:
Liquide
Capacité de remorquage:
S.O.
Suspension avant:
Light Weight Boxed Dual A-Arm with 3 piece Stabilizer Bar and 27.0 in (68.6 cm) *Usable Travel, 22.25 in (56.5 cm) Wheel Travel, Unitized Hubs
Amortisseurs arrière:
3.0 in Walker Evans Velocity Needle Shock with 16-Position Adjustable Clickers
Suspension arrière:
Boxed Trailing Arm with Toe Link, High-Clearance Radius Rods, and 3 Piece Stabilizer Bar and 29.0 in (73.7 cm) *Usable Travel, 24.5 in (62.2 cm) Wheel Travel, Unitized Hubs
Système de contrôle de suspension électronique:
S.O.
Amortisseurs avant:
2.5 in Walker Evans Velocity Needle Shock with 16-Position Adjustable Clickers
