Caractéristiques

Door type	Half doors
Cargo system	Lock & Ride convertible fold-flat rear seat storage with integrated tie-down points, 27.7 x 52.8 x 19.5'' (70.4 x 134.1 x 49.53 cm) factory-equipped cargo liner
Vehicle protection	Bull bumper
Winch	Not equipped

Pneus et roues

Wheels	5-lug, 15'' cast aluminum rim with painted beadlock
Tire ply rating	8-ply
Front tires	32 x 10-15 Pro Armor Trekker wheel size 15 x 7
Rear tires	32 x 10-15 Pro Armor Trekker wheel size 15 x 7

Moteur et transmission

Cylinders displacement	1997 cc
Transmission/final drive	Automatic PVT P/R/N/L/H
Fuel system/battery	Electronic fuel injection
Driveline features	Not equipped
Drive system type	Pro Performance true 2WD/4WD/4WD lock
Engine type	4-stroke DOHC inline four-cylinder
Horsepower	225

Autres spécifications

Security	Polaris P.A.S.S. anti-theft system
Touch screen display	10.4'' (8.3 H x 6.2 W, 1280 x 960 Pixel) Display powered by RIDE COMMAND, featuring
Connected vehicle services	RIDE COMMAND+ connected vehicle services
Rear camera	Digital rear camera
Audio system	Factory-tuned and integrated Rockford Fosgate Stage 4 audio system with RIDE COMMAND source unit. Includes (1) 1500-W 8-channel digital amplifier, (2) 100-W 1'' tweeters, (2) 100-W 6.5'' component front speakers, (2) 100-W 6.5'' coaxial rea

Confort et commodité

Drive modes	Rock, Sport, Race
Cab components	Half doors, aluminum roof
Driver instrumentation	Driver Forward Information Center with 4'' color display + rotary speedometer & tachometers, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, v
Speed limiting	Not equipped
Ride control	Not equipped
Seat type	Front
Electronic power steering	Rack-mounted high-assist electronic power steering with quick-turn rack.
Heat and/or air conditioning	Not equipped
Steering	Race-inspired steering wheel with tilt and telescoping adjustment DYNAMIX and RIDE COMMAND push-button controls.

Dimensions

Ground clearance	16'' (40.6 cm)
Hitch type	Not Equipped
Person capacity	4
Box capacity	300 lbs. (136.1 kg)
Wheelbase	133.5'' (339.1 cm)
Overall vehicle size (l x w x h)	165.5 x 74 x 76.5'' (420 x 188 x 194 cm)
Curb weight	2,769 lbs. (1,256 kg)
Payload capacity	900 lbs. (408.2 kg)
Turning radius	25.0'
Bed box dimensions (l x w x h)	29.5 x 23.8 x 8.1'' (75 x 60.5 x 20.6 cm)

Suspension

Rear shocks	FOX 3.0 Live Valve X2 internal bypass (electronically controlled compression and rebound)
Electronic suspension control system	Polaris Dynamix DV 3.0 (dual valve control) semi-active compression and rebound damping system with selectable ride modes
Front suspension	Lightweight boxed dual A-arm with 3-piece stabilizer bar and 27'' (68.6 cm) usable travel, 22.25'' (56.5 cm) wheel travel, unitized hubs
Rear suspension	Boxed trailing arm with toe link, high-clearance radius rods, 3-piece stabilizer bar, 29.0'' (73.7 cm) usable travel, 24.5'' (62.2 cm) wheel travel, unitized hubs
Front shocks	FOX 3.0 Live Valve X2 internal bypass (electronically controlled compression and rebound)

Specification

Capacité de remorquage	N/A
Poids	2,594 lbs. (1,177 kg)
Capacité du réservoir	12.30 gal. (46.56 L)
Système de refroidissement	Liquid

Éclairage et électricité

Lighting	Signature animated RZR Fang Accent Lighting white LED low/high and red LED tail/brake lights animated interior accent lighting.
Electrical system	High-output 1,700-W charging system @ 3,000 RPM

Freins

Front/rear brakes	4-wheel hydraulic disc with triple-bore front and dual-bore rear calipers aluminum top hat rotor
Parking brake	Park in-transmission
