Pneus et roues

Tire ply rating	8-ply
Front tires	32 x 10-15 Pro Armor Trekker wheel size 15 x 7
Rear tires	32 x 10-15 Pro Armor Trekker wheel size 15 x 7
Wheels	5-lug, 15'' cast aluminum rim with painted beadlock

Dimensions

Person capacity	4
Ground clearance	16'' (40.6 cm)
Curb weight	2,769 lbs. (1,256 kg)
Turning radius	25.0'
Hitch type	Not Equipped
Box capacity	300 lbs. (136.1 kg)
Wheelbase	133.5'' (339.1 cm)
Overall vehicle size (l x w x h)	165.5 x 74 x 76.5'' (420 x 188 x 194 cm)
Payload capacity	900 lbs. (408.2 kg)
Bed box dimensions (l x w x h)	29.5 x 23.8 x 8.1'' (75 x 60.5 x 20.6 cm)

Freins

Parking brake	Park in-transmission
Front/rear brakes	4-wheel hydraulic disc with triple-bore front and dual-bore rear calipers aluminum top hat rotor

Autres spécifications

Touch screen display	10.4'' (8.3 H x 6.2 W, 1280 x 960 Pixel) Display powered by RIDE COMMAND, featuring
Connected vehicle services	RIDE COMMAND+ connected vehicle services
Security	Polaris P.A.S.S. anti-theft system
Audio system	Factory-tuned and integrated Rockford Fosgate Stage 4 audio system with RIDE COMMAND source unit. Includes (1) 1500-W 8-channel digital amplifier, (2) 100-W 1'' tweeters, (2) 100-W 6.5'' component front speakers, (2) 100-W 6.5'' coaxial rea
Rear camera	Digital rear camera

Confort et commodité

Electronic power steering	Rack-mounted high-assist electronic power steering with quick-turn rack.
Drive modes	Rock, Sport, Race
Driver instrumentation	Driver Forward Information Center with 4'' color display + rotary speedometer & tachometers, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, v
Seat type	Front
Speed limiting	Not equipped
Heat and/or air conditioning	Not equipped
Cab components	Half doors, aluminum roof
Steering	Race-inspired steering wheel with tilt and telescoping adjustment DYNAMIX and RIDE COMMAND push-button controls.
Ride control	Not equipped

Specification

Capacité du réservoir	12.30 gal. (46.56 L)
Système de refroidissement	Liquid
Capacité de remorquage	N/A
Poids	2,594 lbs. (1,177 kg)

Éclairage et électricité

Lighting	Signature animated RZR Fang Accent Lighting white LED low/high and red LED tail/brake lights animated interior accent lighting.
Electrical system	High-output 1,700-W charging system @ 3,000 RPM

Moteur et transmission

Transmission/final drive	Automatic PVT P/R/N/L/H
Cylinders displacement	1997 cc
Engine type	4-stroke DOHC inline four-cylinder
Driveline features	Not equipped
Fuel system/battery	Electronic fuel injection
Horsepower	225
Drive system type	Pro Performance true 2WD/4WD/4WD lock

Caractéristiques

Cargo system	Lock & Ride convertible fold-flat rear seat storage with integrated tie-down points, 27.7 x 52.8 x 19.5'' (70.4 x 134.1 x 49.53 cm) factory-equipped cargo liner
Vehicle protection	Bull bumper
Winch	Not equipped
Door type	Half doors

Suspension

Rear shocks	FOX 3.0 Live Valve X2 internal bypass (electronically controlled compression and rebound)
Rear suspension	Boxed trailing arm with toe link, high-clearance radius rods, 3-piece stabilizer bar, 29.0'' (73.7 cm) usable travel, 24.5'' (62.2 cm) wheel travel, unitized hubs
Front shocks	FOX 3.0 Live Valve X2 internal bypass (electronically controlled compression and rebound)
Front suspension	Lightweight boxed dual A-arm with 3-piece stabilizer bar and 27'' (68.6 cm) usable travel, 22.25'' (56.5 cm) wheel travel, unitized hubs
Electronic suspension control system	Polaris Dynamix DV 3.0 (dual valve control) semi-active compression and rebound damping system with selectable ride modes
