Dimensions

Person capacity	4
Curb weight	2,769 lbs. (1,256 kg)
Box capacity	300 lbs. (136.1 kg)
Wheelbase	133.5'' (339.1 cm)
Overall vehicle size (l x w x h)	165.5 x 74 x 76.5'' (420 x 188 x 194 cm)
Hitch type	Not Equipped
Ground clearance	16'' (40.6 cm)
Turning radius	25.0'
Payload capacity	900 lbs. (408.2 kg)
Bed box dimensions (l x w x h)	29.5 x 23.8 x 8.1'' (75 x 60.5 x 20.6 cm)

Suspension

Rear shocks	FOX 3.0 Live Valve X2 internal bypass (electronically controlled compression and rebound)
Front shocks	FOX 3.0 Live Valve X2 internal bypass (electronically controlled compression and rebound)
Rear suspension	Boxed trailing arm with toe link, high-clearance radius rods, 3-piece stabilizer bar, 29.0'' (73.7 cm) usable travel, 24.5'' (62.2 cm) wheel travel, unitized hubs
Front suspension	Lightweight boxed dual A-arm with 3-piece stabilizer bar and 27'' (68.6 cm) usable travel, 22.25'' (56.5 cm) wheel travel, unitized hubs
Electronic suspension control system	Polaris Dynamix DV 3.0 (dual valve control) semi-active compression and rebound damping system with selectable ride modes

Freins

Front/rear brakes	4-wheel hydraulic disc with triple-bore front and dual-bore rear calipers aluminum top hat rotor
Parking brake	Park in-transmission

Caractéristiques

Winch	Not equipped
Door type	Half doors
Cargo system	Lock & Ride convertible fold-flat rear seat storage with integrated tie-down points, 27.7 x 52.8 x 19.5'' (70.4 x 134.1 x 49.53 cm) factory-equipped cargo liner
Vehicle protection	Bull bumper

Pneus et roues

Tire ply rating	8-ply
Rear tires	32 x 10-15 Pro Armor Trekker wheel size 15 x 7
Front tires	32 x 10-15 Pro Armor Trekker wheel size 15 x 7
Wheels	5-lug, 15'' cast aluminum rim with painted beadlock

Moteur et transmission

Horsepower	225
Driveline features	Not equipped
Fuel system/battery	Electronic fuel injection
Transmission/final drive	Automatic PVT P/R/N/L/H
Drive system type	Pro Performance true 2WD/4WD/4WD lock
Engine type	4-stroke DOHC inline four-cylinder
Cylinders displacement	1997 cc

Confort et commodité

Steering	Race-inspired steering wheel with tilt and telescoping adjustment DYNAMIX and RIDE COMMAND push-button controls.
Heat and/or air conditioning	Not equipped
Electronic power steering	Rack-mounted high-assist electronic power steering with quick-turn rack.
Driver instrumentation	Driver Forward Information Center with 4'' color display + rotary speedometer & tachometers, programmable service intervals, speedometer, tachometer, odometer, tripmeter, clock, hour meter, gear indicator, fuel gauge, coolant temperature, v
Seat type	Front
Ride control	Not equipped
Speed limiting	Not equipped
Cab components	Half doors, aluminum roof
Drive modes	Rock, Sport, Race

Specification

Poids	2,594 lbs. (1,177 kg)
Système de refroidissement	Liquid
Capacité de remorquage	N/A
Capacité du réservoir	12.30 gal. (46.56 L)

Autres spécifications

Audio system	Factory-tuned and integrated Rockford Fosgate Stage 4 audio system with RIDE COMMAND source unit. Includes (1) 1500-W 8-channel digital amplifier, (2) 100-W 1'' tweeters, (2) 100-W 6.5'' component front speakers, (2) 100-W 6.5'' coaxial rea
Touch screen display	10.4'' (8.3 H x 6.2 W, 1280 x 960 Pixel) Display powered by RIDE COMMAND, featuring
Rear camera	Digital rear camera
Security	Polaris P.A.S.S. anti-theft system
Connected vehicle services	RIDE COMMAND+ connected vehicle services

Éclairage et électricité

Electrical system	High-output 1,700-W charging system @ 3,000 RPM
Lighting	Signature animated RZR Fang Accent Lighting white LED low/high and red LED tail/brake lights animated interior accent lighting.
