Dimensions

Hitch type	Standard 2'' (5 cm) receiver
Payload capacity	1,710 lbs. (775 kg)
Curb weight	2,886 lbs. (1309 kg)
Bed box dimensions (l x w x h)	43.4 x 56 x 13.4'' (110.2 x 142.2 x 34 cm)
Wheelbase	95'' (241.3 cm)
Ground clearance	15'' (38 cm)
Box capacity	1,500 lbs. (680 kg)
Turning radius	15.1 ft (4.6 m)
Overall vehicle size (l x w x h)	137 x 65 x 78'' (348 x 165 x 198 cm)
Person capacity	3

Confort et commodité

Steering	Tilt & telescoping adjustment
Electronic power steering	High-output EPS
Seat type	3-person, superior contoured and bolstered bench seat with 3-point harness, adjustable driver seat, and flip-down arm rest
Heat and/or air conditioning	Factory-installed heat, AC, defrost, recirculation with 5 different airflow settings
Driver instrumentation	Driver forward information center with 4'' color display and analog speedometer and tachometers
Speed limiting	Speed limiting controlled in gauge
Cab components	Factory-installed cab system with powered doors, roof, fixed glass windshield, glass rear panel, rearview mirror, windshield wiper/washer, and sound insulation materials

Technologie

Touch screen display	Not equipped, accessory options available
Security	Polaris P.A.S.S. anti-theft system
Rear camera	Not equipped
Connected vehicle services	Not equipped, accessory options available
Audio system	Not equipped, accessory options available

Specification

Capacité du réservoir	13.6 gal (51.5 L)
Capacité de remorquage	3,500 lbs. (1588 kg)
Système de refroidissement	Liquide
Poids	2,790 lbs. (1265 kg)

Moteur et transmission

Transmission/final drive	STEELDRIVE automatic transmission
Engine type	4-stroke triple cylinder DOHC
Horsepower	110
Driveline features	Drive mode-specific engine braking, hill assist, and creep in drive and reverse
Cylinders displacement	1498 cc
Fuel system/battery	Electronic fuel injection
Drive system type	Selectable on-demand all-wheel drive, AWD/2WD/Turf/Ultra Turf, Drive modes

Pneus et roues

Pneus avant	30 x 10-15 KENDA® CROSS TRAIL
Tire ply rating	8-ply
Wheels	15'' aluminum
Pneus arrière	30 x 11-15 KENDA® CROSS TRAIL

Éclairage et électrique

Lighting	LED headlights with LED taillights, LED dome light, door puddle lighting, interior accent lighting, lighting modes
Electrical system	140-amp charging system, Polaris PULSE electrical system (3-position hood and 3-position roof), USB charger, trickle charger, 12-volt accessory outlet, battery trickle-charging port

Freins

Front/rear brakes	Foot-activated and power-assisted, 4-wheel hydraulic disc with dual-bore front and rear calipers
Parking brake	Park in-transmission

Suspension

Front suspension	Dual A-arm 12'' (30.5 cm) travel
Rear suspension	Dual arched A-arm, IRS 12'' (30.5 cm) travel

Caractéristiques extérieures

Winch	Pro Series 6,000 LB Winch with synthetic rope, Auto Stop, wireless remote and Rapid Rope Recovery
Door type	Powered window doors
Cargo system	Electronic lift dump box with Lock & Ride MAX accessory integration
Vehicle protection	Large steel bumper, full-coverage skid plate
